JIANGSU WANSHIDA HYDRAULIC MACHINERY CO., LTD
| Place of Origin: | China |
|---|---|
| Brand Name: | WANSHIDA |
| Certification: | CE, ISO9001 |
| Model Number: | Y83/D |
| Minimum Order Quantity: | 1 set |
| Delivery Time: | 25 days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 30 sets/month |
| Certification：: | CE, ISO9001 And ISO14000 | Model Number: | Y82-25 |
|---|---|---|---|
| Stroke: | 1000 Mm | Hydraulic System Pressure: | 21 MPa |
| Power: | 11 KW | Weight: | 1800kg |
| High Light: | Y82-25 Vertical Baler Machine,CE Certificate Vertical Plastic Baler,Vertical Plastic Baler Y82-25 |
||
| Place of Origin | Jiangsu, China |
| Brand Name | Wanshida |
| Certification | CE, ISO9001 and ISO14000. |
| Model Number | Y82-25 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Seaworthy |
| Delivery Time: | 15 days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 30 sets/month |
Product Details
China WANSHIDA Y82-25 Drum Crusher Drum Compactors Drum Press Manufacturer CE certificate
We are China drum crusher manufacturer-Wanshida Hydraulic Machinery. We have more than 20 years experience in researching and developing metal baler presses, metal cutting machine, etc.
1. The Y82-25 Drum Crusher is a compact electro hydraulically operated 208L barrel press. And the compressed height is Min. 60mm. With its 30 Tons pressing force, this machine is suitable for both light steel drums, or rolling hoop barrels, any residual fluids discharge during compaction are collected in a 30-liter collection tank, which can be drained easily through an integral tap.
Y82-25 Used Drum Crusher is used to compress 200L steel drums.
And the compressed height is Min. 60mm.
2. The technical parameters:
| SN. | Name and Content of Parameter | Remark | ||
| 1 | Main Hydraulic CYLD | Type | YG125/80-1000 | |
| Max.Push force | 250 kN | 25 ton | ||
| Stroke | 1000 mm | |||
| 2 | Compress box size(LWH) | 7907901060 mm | ||
| 3 | Size of baled block(H) | Min. 60 mm | ||
| 4 | Hydraulic system pressure | 21 MPa | ||
| 5 | Electromotor | Type | Y 160M -4 | |
| Power | 11 kW | |||
| Rated speed | 1460 rpm | |||
| 6 | Oil pump | Type | 40YCY14-1B | |
| Nominal discharge | 40 ml/r | |||
| Nominal pressure | 31.5 MPa | |||
| 7 | Overall size(LWH) | 115015002950mm | ||
| 8 | Weight | 1800kg | ||
4. Quality: This machine apply to ISO9001: 2000 standard.
5. Service:
1) One year guarantee and lifelong maintenance;
2) Any problem, you can call us directly.
