Mobile Diesel Scrap Metal Baler with Grapple for Recycling Yards and On-Site Scrap Collection

Mobile Diesel Scrap Metal Baler with Grapple for Recycling Yards and On-Site Scrap Collection

The Y83D-3000A Mobile Baler Shear is a compact yet high-performance diesel-powered scrap metal baling solution designed for recycling companies, scrap collection stations, demolition contractors, and mobile metal processing operations. Combining mobility, hydraulic compression, and grapple loading into one integrated unit, this machine enables users to process loose scrap metal directly at the collection site, reducing transportation costs while improving recycling efficiency.

Powered by an 86kW diesel engine, the Y83D-3000A operates independently without relying on external electricity, making it an ideal solution for remote recycling yards, temporary job sites, construction projects, and locations where industrial power is unavailable or unstable. The 160-ton hydraulic pushing force delivers reliable compression performance while maintaining stable production capacity of 5–7 tons per hour.

Its large 3000×1620×620mm loading chamber accepts various light and medium-density scrap materials, allowing operators to load bulky scrap quickly with the integrated 1800kg grapple. After compression, loose scrap is transformed into dense 500×400×400mm bales, significantly reducing storage space and transportation expenses while increasing scrap value.

Designed for continuous outdoor operation, the machine is equipped with an air-cooled hydraulic oil system that helps maintain stable oil temperature and extends hydraulic component life. The trailer-mounted structure allows operators to relocate the equipment between multiple recycling sites, providing outstanding flexibility for businesses handling scattered scrap resources.

For companies seeking higher operational efficiency, lower labor costs, and improved logistics, the Y83D-3000A offers an economical and reliable mobile recycling solution backed by decades of hydraulic engineering experience.

Cause

Scrap metal recycling businesses often struggle with loose materials occupying excessive yard space and requiring multiple handling steps before transportation. Moving uncompressed scrap to centralized processing plants increases fuel costs, loading time, and labor expenses.

Many recycling stations are also located in areas without reliable electrical infrastructure. Traditional stationary balers require permanent installation and significant civil construction, limiting operational flexibility.

Furthermore, using separate loading equipment and fixed balers often results in higher investment and increased operating costs. These challenges reduce overall productivity and profitability, particularly for companies processing scrap across multiple locations.

Solution

The Y83D-3000A Mobile Baler Shear addresses these challenges by integrating mobility, hydraulic compression, diesel power, and grapple feeding into one efficient machine.

Its trailer-mounted design allows operators to transport the equipment directly to demolition sites, recycling yards, or temporary collection points. The diesel engine eliminates dependence on external power supplies, while the integrated grapple minimizes manual loading and reduces the need for additional machinery.

The 160-ton hydraulic system compresses loose scrap into dense rectangular bales that are easier to transport, stack, and sell. Combined with the air cooling system and robust hydraulic structure, the machine delivers reliable performance during long working hours with minimal downtime.

Specifications

Application

The Y83D-3000A is suitable for processing a wide variety of recyclable ferrous and non-ferrous metals.

Typical applications include:

• Scrap metal recycling yards

• Mobile recycling contractors

• Construction and demolition projects

• Steel processing plants

• Automobile dismantling facilities

• Metal collection centers

• Industrial manufacturing waste recycling

Suitable materials include:

• Steel sheet

• Light steel scrap

• Aluminum scrap

• Copper scrap

• Stainless steel offcuts

• Metal profiles

• Appliance housings

• Vehicle body panels

• Mixed light scrap

The compact bale size helps improve container loading efficiency while reducing transportation frequency and storage requirements.

How It Works

The operator uses the integrated grapple to collect loose scrap and place it into the spacious compression chamber. Once sufficient material has been loaded, the hydraulic cylinders begin compressing the scrap under a maximum pressure of 20MPa.

The 160-ton pushing force compacts the material into dense rectangular bales measuring approximately 500×400×400mm. After compression is complete, the bale is discharged, ready for stacking, transportation, or further processing such as shredding or steel melting.

The entire hydraulic system is powered by the onboard 86kW diesel engine, allowing the machine to operate efficiently in outdoor environments without electrical infrastructure. Meanwhile, the air cooling system maintains stable hydraulic oil temperature, ensuring consistent performance during continuous production.

How To Choose

Choosing the right mobile baler shear depends on your scrap type, production capacity, operating environment, and transportation requirements.

The Y83D-3000A is an excellent choice if your business processes 5–7 tons of light or medium scrap per hour and frequently works across multiple locations. It is particularly suitable for businesses that require a compact machine with excellent mobility while maintaining strong compression performance.

If your recycling yard has limited electrical infrastructure, the diesel-powered design provides complete operating independence. Customers seeking to reduce labor costs will also benefit from the integrated grapple, which speeds up material loading and minimizes the need for additional handling equipment.

For larger production capacities or heavier scrap materials, our engineering team can also recommend higher-capacity mobile baler shear models with customized configurations to match your operational requirements.

FAQ

Q1: What types of scrap can this machine process?

A: The Y83D-3000A is designed for light and medium scrap up to 3mm thick, including steel sheet, aluminum scrap, stainless steel, copper scrap, appliance shells, vehicle panels, and other recyclable metal materials.

Q2: Why choose a diesel-powered mobile baler instead of an electric stationary baler?

A: A diesel-powered mobile baler provides maximum flexibility. It can operate directly at remote recycling sites without external electricity, reducing transportation costs and improving overall productivity.

Q3: Does the machine include its own loading equipment?

A: Yes. The integrated grapple has a lifting capacity of 1800kg, allowing operators to load loose scrap efficiently while reducing labor requirements and dependence on additional machinery.

Q4: Can the machine operate continuously outdoors?

A: Yes. The air-cooled hydraulic oil system helps maintain stable operating temperatures, making the machine suitable for continuous outdoor operation in demanding working environments.

Q5: Can the machine be customized?

A: Absolutely. We can customize bale size, operating configuration, hydraulic system, grapple specification, trailer design, and other features according to your material characteristics, production target, and local operating conditions.
