35 Ton Y82-35F Vertical Material Baler With 1200 × 800 Mm Bale Section For Cardboard, Plastic And Light Waste Recycling

The Y82-35F vertical material baler is a compact hydraulic compression machine developed for small and medium-sized recycling centers, warehouses, manufacturing plants, supermarkets, logistics facilities and packaging waste collection areas.

It is designed to compress loose, low-density materials such as cardboard, plastic film, woven bags, textiles, foam packaging and other recyclable waste into regular bales that are easier to store, handle and transport.

The machine is equipped with a 1200 × 800 × 1600 mm loading chamber, providing sufficient space for bulky packaging waste. The finished bale has a fixed cross-section of 1200 × 800 mm, while the bale height can be controlled from approximately 300 to 1200 mm, depending on the material volume, number of compression cycles and required bale weight.

The Y82-35F vertical hydraulic baler uses a 7.5 kW hydraulic pump motor and operates at a hydraulic system pressure of 23 MPa. Its vertical structure reduces floor-space requirements and makes the machine suitable for facilities that need a practical waste-volume reduction solution without investing in a large fully automatic horizontal baling line.

Core SEO keywords naturally included in this description are: 35 ton vertical baler, Y82-35F hydraulic baler, vertical material baling machine, cardboard baler, plastic waste baler, hydraulic recycling baler, 1200 × 800 mm bale press and vertical waste compacting equipment.

Cardboard boxes, plastic film, woven bags and textile waste are generally lightweight but occupy a large amount of space when stored loose. Many factories do not generate extremely high waste tonnage, yet their recycling materials quickly fill warehouse corners, loading areas and production passages.

Common customer problems include:

Loose cardboard and plastic packaging contain a large amount of air. Even a relatively small amount of material can occupy a considerable area.

Uncompressed light waste leaves large empty spaces inside trucks and containers. A vehicle may be full in volume but still carry an uneconomically low weight.

Manually folding, stepping on or bagging recyclable waste requires labor and does not produce stable, stackable packages.

Many downstream recyclers prefer classified and compacted materials. Regular bales are normally easier to weigh, load and process than loose waste.

A fully automatic horizontal baler may be unnecessary for a customer with moderate daily waste generation. A vertical hydraulic baler offers a more compact and economical alternative.

The Y82-35F vertical material baler uses a hydraulic cylinder to drive the pressing platen downward. Loose material placed inside the chamber is compressed repeatedly until the required bale height and density are achieved.

The compressed material can then be secured with steel wire, plastic strapping or another suitable binding material.

The machine helps customers:

• Reduce the volume of cardboard, plastic and packaging waste;
• Improve the use of warehouse and workshop space;
• Produce regular bales with a 1200 × 800 mm cross-section;
• Adjust bale height according to transport and storage requirements;
• Reduce empty space inside trucks and containers;
• Lower repeated handling and material-cleaning costs;
• Improve waste classification and workplace organization;
• Process recyclable waste with a relatively low 7.5 kW installed power.

The machine footprint is approximately 1900 × 1100 mm, making it suitable for installation beside a production line, inside a warehouse, near a loading dock or in a dedicated waste collection area.

Because the total equipment height is approximately 3800 mm, the available building height and maintenance clearance should be checked before installation.

The actual bale weight depends on the material type, moisture content, bulk density, spring-back characteristics and number of loading cycles.

The 1200 × 800 × 1600 mm chamber accommodates bulky cardboard, plastic bags and other loose materials, reducing the need for extensive manual cutting or folding.

The bale cross-section remains 1200 × 800 mm, while the height can be adjusted between approximately 300 and 1200 mm. This helps customers match bale weight to forklift capacity, truck dimensions and downstream recycling requirements.

Compared with large horizontal balers, the Y82-35F has a relatively low installed motor power, making it suitable for small and medium-volume waste-processing applications.

With an approximate footprint of 1900 × 1100 mm, the machine uses vertical space efficiently and is suitable for facilities with limited floor area.

The hydraulic system operates at 23 MPa, while the pump has a rated pressure of 31.5 MPa. This configuration supports stable platen movement and reliable compression.

Manual hydraulic control allows the operator to manage the downward and return movements directly. The uncomplicated structure also makes routine inspection of hydraulic oil, hoses and seals easier.

Regular bales are easier to stack, weigh, move with a forklift and load into trucks or containers.

The Y82-35F vertical hydraulic baler can be used for compressing:

• Waste cardboard and corrugated boxes;
• Paper, books and packaging paper;
• PET bottles and selected empty plastic containers;
• Plastic film and flexible packaging;
• Woven polypropylene bags and bulk bags;
• Cotton fabric, used clothing and textile offcuts;
• Foam, sponge and lightweight packaging materials;
• Aluminum cans and light metal packaging;
• Flexible industrial packaging waste;
• Recyclable materials from warehouses and logistics centers.

Typical users include:

• Recycling stations;
• Cardboard and packaging plants;
• Plastic product manufacturers;
• Garment and textile factories;
• Supermarkets and distribution centers;
• E-commerce warehouses;
• Printing and paper-product companies;
• Industrial waste-management departments.

The machine is primarily intended for light and compressible materials. Thick steel plates, solid metal blocks, heavy structural steel and other high-strength materials should not be loaded without technical confirmation.

1. Material sorting
   Remove stones, solid metal pieces and other unsuitable contaminants. Separate different recyclable materials when required.
2. Chamber loading
   Open the loading door and place cardboard, plastic film, woven bags or other waste into the 1200 × 800 × 1600 mm chamber.
3. Hydraulic system start-up
   The 7.5 kW motor drives the hydraulic pump and supplies pressurized oil to the main cylinder.
4. Downward compression
   The cylinder moves the platen downward to compress the material. The full downward stroke takes approximately 40 seconds.
5. Repeated loading
   Bulky materials normally require several loading and pressing cycles before the desired bale height is reached.
6. Bale binding
   Steel wire or plastic straps are used to secure the compressed material and limit spring-back.
7. Platen return
   The platen returns to its upper position. The full return stroke takes approximately 20 seconds.
8. Bale removal
   The finished bale is removed and transferred with a forklift, pallet truck or suitable handling equipment.

Cardboard, plastic film, textiles and aluminum cans have different densities and spring-back characteristics. Providing clear material photos and videos helps the supplier evaluate suitability.

The Y82-35F is suitable for intermittent and moderate-volume operation. Customers with continuous high-volume cardboard or plastic waste may require a larger horizontal baler with automatic feeding and bale discharge.

The machine produces a 1200 × 800 mm bale cross-section. Customers should confirm whether this size matches their pallets, forklifts, trucks and downstream recycler requirements.

The machine height is approximately 3800 mm. Additional top clearance should be reserved for installation and cylinder maintenance.

The standard motor power is 7.5 kW. Voltage, frequency and phase should be confirmed before production, such as 380 V / 50 Hz / 3 Phase or another local industrial supply.

The final bale weight varies according to the material. A forklift, pallet truck or other suitable handling solution should be prepared when heavy bales are expected.

The Y82-35F is mainly designed for manual loading and hydraulic operation. For continuous feeding, high output or reduced labor requirements, an automatic conveyor and horizontal baling system may be more suitable.

It is suitable for cardboard, paper, plastic film, woven bags, textiles, PET bottles, foam and other light compressible waste. Suitability depends on material hardness, size and spring-back behavior.

There is no fixed bale weight. Cardboard, plastic film, textiles and aluminum cans have different densities. A material test is recommended when a specific bale weight is required.

Yes. The bale cross-section is 1200 × 800 mm, while the bale height can be controlled between approximately 300 and 1200 mm.

Yes. The motor and electrical system can be configured according to the customer’s local voltage, frequency and phase requirements.

The standard model is more suitable for intermittent and moderate-volume operation. For continuous heavy-duty use, customers should provide the hourly capacity, daily operating hours and material type so that the hydraulic cooling and machine configuration can be evaluated.

Available service support includes:

• Installation and operating guidance;
• English operation manual and basic technical documents;
• Electrical and hydraulic instructions;
• Factory testing before shipment;
• Testing photos and operating videos;
• Recommended spare-parts and wear-parts list;
• Remote video commissioning assistance;
• Voltage, chamber and bale-size customization;
• Warranty support and long-term spare-parts supply;
• Material evaluation and test-baling recommendations.

After installation, the customer should inspect the hydraulic oil level, motor rotation direction, fasteners and safety devices before operation. Clean hydraulic oil should be used, and filters, hoses and seals should be inspected regularly according to the operating frequency.
