Consistent 22 kW Export-Ready Metal Shredder for Customized Overseas Recycling Projects

Consistent 22 kW Export-Ready Metal Shredder for Customized Overseas Recycling Projects

Product Overview

The Q43P-1000A Metal Shredder is designed for overseas recycling projects that require equipment to match local power conditions, workshop layouts and production processes. Instead of supplying one fixed configuration to every market, the electrical system, operating controls, feeding method and discharge arrangement can be adapted to the buyer’s actual site.

The machine is equipped with 33 blades, each measuring 300 mm in diameter and 30 mm in thickness. Two 11 kW motors drive the cutting system at 16 rpm, providing a reference capacity of 2–3 m³/h. After processing, suitable metal scrap is reduced to pieces of approximately 30 × 40 mm.

Its 1010 × 720 mm hopper opening and 1010 × 550 mm shredding chamber provide a practical balance between loading convenience and processing capability. The machine is manufactured according to ISO 9001 quality management requirements, with factory inspection conducted before export.

Cause

Imported recycling equipment must satisfy more than a production-capacity target. Differences in industrial voltage, factory space, operating habits and local maintenance resources can directly affect installation and long-term use.

A machine may have suitable technical parameters but still cause difficulties if important project conditions are not confirmed before production. International buyers commonly need to consider:

• Local voltage and frequency
• Available power capacity
• Workshop entrance and installation space
• Preferred control language
• Feeding and material-discharge direction
• Connection with existing equipment
• Availability of replacement parts
• Remote installation and commissioning support

Solution

The Q43P-1000A can be configured around the buyer’s operating environment. Before production, the material information and site conditions are reviewed to determine whether the standard model is suitable or whether adjustments are required.

Project-specific options may include:

• Electrical configuration for local power standards
• Control-panel language customization
• Feeding and discharge conveyor selection
• Equipment color customization
• Spare blade and wear-part packages
• Factory trial testing with similar materials
• Operating manuals and electrical documentation
• Remote technical guidance after delivery

This project-based approach helps reduce installation uncertainty and ensures that the shredder can be incorporated into the buyer’s existing workflow.

Specifications

Application

The Q43P-1000A can be supplied for overseas projects involving:

• Metal fabrication waste
• Aluminum processing leftovers
• Light sheet-metal scrap
• Metal packaging materials
• Thin-wall rejected components
• Hardware production waste
• Pre-sorted recyclable metal

It can be installed as an independent shredding unit or incorporated into a localized recycling project. The final configuration should be confirmed according to the material, processing target and site conditions.

How It Works

Suitable scrap is loaded into the hopper and guided into the shredding chamber. Two motor-driven shafts rotate at low speed, allowing the blades to grip and pull material into the cutting area.

The material is progressively torn and sheared into smaller pieces. Processed scrap exits through the lower discharge section and can be collected directly or transferred to other equipment.

Before shipment, the operating direction, motor performance, blade movement and electrical controls can be tested at the factory. Inspection photos and trial videos can be provided for buyer confirmation.

How To Choose

For an overseas project, model selection should include both material analysis and installation planning. Buyers are advised to provide:

• Scrap photos and videos
• Material composition and thickness
• Maximum feeding dimensions
• Required capacity and output size
• Local voltage, phase and frequency
• Workshop dimensions
• Existing equipment information
• Preferred feeding and discharge method

These details allow the machine configuration to be reviewed before manufacturing, helping avoid costly site modifications after delivery.

FAQ

Can the electrical system match my country’s voltage?

Yes. The voltage, frequency and electrical components can be configured according to the buyer’s local industrial power supply.

Will the machine be tested before shipment?

Yes. Factory testing can cover mechanical operation, motor performance, control functions and trial shredding when suitable test materials are available.

What documents are supplied with the shredder?

Operating instructions, electrical information and relevant equipment documents can be supplied according to the final contract configuration.

Can spare blades be ordered with the machine?

Yes. Buyers can purchase a recommended spare-parts package together with the shredder to support future maintenance.

Is overseas installation support available?

Remote installation and commissioning guidance can be provided. On-site service arrangements can also be discussed according to the project location and requirements.
